FS25 Fliegl ZHKA 350 V1.0

Fliegl Agrartechnik GmbH – the ZHKA 350 trailer is a large tipping semi-trailer designed primarily for agricultural and heavy-duty use, suitable for towing by powerful tractors or agro-trailers for transporting bulk materials such as grain, silage, wood chips or manure.
Basic description
The Fliegl ZHKA 350 is a two-axle tipping semi-trailer with a robust construction and large loading capacity – ideal for agro and demanding transport of heavy bulk cargo.
Technical data (typical basic equipment)
Total permissible weight: 31,000 kg
Fifth wheel load: approx. 11,000 kg
Rear axle load: up to 20,000 kg
Loading body: aluminum with a volume of approx. 49 m³
Body dimensions: approx. 9,300 × 2,150 × ~2,420 mm (width at the rear)
Hitch height: approx. 1,400 mm
Axles: 2 fixed axles with drum brakes
Tires: 600/55-26.5
Brake system: dual-circuit air system
Lighting: 24 V with 15-pin socket
Max. permitted speed: 60 km/h (German version)
Design and equipment
The aluminum body made of hollow side profiles is lightweight and corrosion-resistant, while optimizing the weight for a higher payload.
Tipping tailgate with special double hinges and hook locks – for fast and safe emptying.
Hydraulic tilt control via the tractor’s power take-off shaft (PTO) with high-pressure connection.
Roll-up tarpaulin with platform to secure the load against falling out and weather.
LED work lights for better lighting during loading/unloading.
Practical use
Agriculture: transport of grain, seeds, silage, manure, corn and other bulk materials.
Forestry/biomass: wood chips, wood or other heavy materials.
Construction: transport of bulk building materials.
